LUMEN X+™

Learn more

Lumen X™ bioprinter, powered by Volumetric, offers high-resolution, high-throughput and high-fidelity bioprinting, enhancing applications in microfluidics, cell-laden hydrogels, macroporous structures and more. When used to bioprint vasculature, Lumen X’s biocompatible blue light gives you a powerful advantage in achieving complex branching and tapering of vessels.

Get a quote

Description

Features

  • 405 nm projector uses over 1 million points of light to photographically cure entire layers in seconds.
  • Crosslinks structures 50 times faster than other printing methods.
  • A portfolio of biocompatible hydrogels is available. They are optimized for the LUMEN X+™ DLP bioprinter in order to reliably bioprint precise and reproducible constructs. A variety of stiffnesses, levels of optical clarity and strength have been developed to suit research needs.
  • Combines with extrusion-based bioprinters to multiply the benefits of each system’s state-of-the-art capabilities.
  • Use the BIO X™ or BIO X6™ bioprinters to print living cells within a structure fabricated on the LUMEN X+ DLP bioprinter.
  • Strengthen work in applications such as organon-a-chip and multimaterial research.
  • Learn how to use the light-based LUMEN X+ and the BIO X6 extrusion-based bioprinter to biofabricate bioreactors in our latest application note.

PhotoInks Compatible with the LUMEN X+

LUMEN X+ accessories

  • PDMS Dishes
  • Build Platform
    Available in glass bottom and metal bottom varieties and easily swappable to run print after print with little downtime.
  •  Light Meter
    Validates light intensity for optimal material development, data collection and maintenance.

Specifications

Projected image 1280 x 800 pixels
Pixel resolution (XY) 50 μm
Z-precision (motor-driven) μm
Max build volume 64 x 40 x 50 mm
Software LightField (Integrated)
Supported file types .STL
Connectivity USB
Machine size (H/W/D) 480 x 440 x 355 mm
Machine weight 9 kg (20 lbs)
Shipping weight 13.6 kg (30 lbs)
Power input 100-265VAC, 50-60Hz, 100W

Resources

Documents
